[eptar] Reinforcement 2.0

This solution helps designers to draw documents and lists the necessary reinforcement for their buildings in ArchiCAD. The application provides tools to define all 2D drawings as well as complete 3D models.

Our simple solution contains a library of reinforcement objects and an Add-on. They provide great freedom in defining constructions and also help to specify complex objects. What's more, Eptar Reinforcement checks the rebar ID numbering and corrects it if is necessary. With our tool, users can simply calculate the necessary amount of rebars. Iron list is available on the floor plan just as the interactive schedule.

Overview of the features:

  • Most used rebar and stirrup forms are preset, but custom polygonal forms can be set too

  • Steel elements can be rotated, thus more difficult constructions (e.g. stairs) can be modeled

  • Complex elements (columns, beams and crownings) can be defined

  • Many view and display options

  • Cutting list generation

  • Automatic correction of enumeration

  • Changes can easily be made on the layout and in the Object Settings window as well

  • Automatic reinforcement of walls

  • Several walls or slabs can be reinforced with a single selection

  • Multiple layers of rebar can be placed at a time
